RG 58 C/U

Solid PE Insulated Cable, 4.95mmOD, 50ohm

rg 58 cable structure

MECHANICAL DATA



ITEM                     MATERIAL       DIAMETER             REMARK



CENTER CONDUCTOR   TC                  0.90±0.02mm          Strand 19/0.182mm

DIELECTRIC               PE                  2.95±0.15mm         SOLID

OUTER SHIELD          TC                  3.60±0.15mm         96%(nom.)

JACKET                     PVC               4.95±0.20mm         BLACK



* TC: Tin Copper

* PE: PolyEthylene

* PVC: Polyvinyl Chloride



ELECTRICAL DATA



ITEM                              SPECIFICATION



CAPACITANCE                   101.0 pF/m (30.8 pF/FT) (nom.)

CHARACTERISTIC IMPEDANCE  50±3

OPERATING FREQUENCY           1 GHz

OPERATING TEMP                  -40 +85

OPERATING VOLTAGE            1,900 vrms (max.)

WEIGHT                             38.6 kg/Km

MAXIMUM ATTENUATION

Frequency (MHz)               dB/100ft (dB/M)             Power (Watts)



              100                4.8(0.16)              -

              200                6.7(0.22)              -

              400                9.7(0.32)              -

              800               15.2(0.50)             -

            1,000               17.3(0.57)             -

            2,000               26.2(0.86)             -

            3,000               35.0(1.15)             -

            5,000               46.6(1.53)             -
