    Home > Product > RF Cables > Semi Rigid Cable


 [RUT047TP]//[RUT085TP]//[RUT141TP]//[RUT250TP]//[RUT250ALTP]



RUT 047 TP

Semi Rigid Cable. 0.047 Size, 50 Ohm Cu/Tin by Specification Mil-C-17/151

Semi rigid cable structure

MECHANICAL DATA



ITEM                     MATERIAL       DIAMETER             REMARK



CENTER CONDUCTOR   SPCW             0.29±0.02mm

DIELECTRIC               PTFE              0.92±0.03mm      SOLID

OUTER SHIELD          Tinned Copper    1.19±0.03mm     TUBE/100% COVERAGE



* SPCW: Silver Plated Copper clad steel Wire



ELECTRICAL DATA



ITEM                              SPECIFICATION



BEND RADIUS   3.0 mm (min.)

CONDUCTOR RESISTANCE         207.3 Ohms/Mft at 20 (max.)

CAPACITANCE                   95.1 pF/m (29.0 pF/ft) (nom.)

CHARACTERISTIC IMPEDANCE  50 +/- 3 ohms

CORONA EXTINCTION VOLTAGE 1,000 vrms @ 60 Hz

OPERATING FREQUENCY           20 GHz (max.)

OPERATING TEMP                  -40 +125

VELOCITY OF PROPAGATION     69.5% (nom.)

VOLTAGE WITHSTANDING          3,500 vrsm @ 60 Hz

RoHS Compliant                             YES

WEIGHT            5.6 kg/km (0.47 lbs/100ft)

MAXIMUM ATTENUATION

Frequency (MHz)               dB/100ft (dB/M)  Power (Watts)



               500               23.1(0.75)         66.5

             1,000               33.4(1.09)         47.0

             5,000               79.3(2.60)         21.9

            10,000              114.5(3.75)         15.3

            20,000              168.2(5.51)         10.5
