 [Mini Coaxial Cables]



1. CONSTRUCTION
0.81 OD type
NO ITEM MTERIAL DIAMETER REMARK
Center Conductor SPCW 0.15 ± 0.02mm Strand 7/0.05mm
Dielectric FEP 0.40 ± 0.03mm SOLID
Outer Shield TC 0.65 ± 0.15mm
Jacket FEP 0.81 ± 0.10mm WHITE

1.13 OD type
NO ITEM MTERIAL DIAMETER REMARK
Center Conductor SPCW 0.24 ± 0.02mm Strand 7/0.08mm
Dielectric FEP 0.68 ± 0.03mm SOLID
Outer Shield TC 0.90 ± 0.15mm
Jacket FEP 1.13 ± 0.10mm GY/BK

1.30/Single
NO ITEM MTERIAL DIAMETER REMARK
Center Conductor SPCW 0.24 ± 0.02mm Strand 7/0.08mm
Dielectric FEP 0.68 ± 0.03mm SOLID
Outer Shield TC 0.90 ± 0.15mm
Jacket FEP 1.30 ± 0.10mm GY/BK

1.32/Double
NO ITEM MTERIAL DIAMETER REMARK
Center Conductor SPCW 0.24 ± 0.02mm Strand 7/0.08mm
Dielectric FEP 0.68 ± 0.03mm SOLID
Outer Shield TC 1.05 ± 0.15mm
Jacket FEP 1.32 ± 0.10mm GY/BK
  * SPCW : Silver Plated Copper clad steel Wire
* TC : Tinned Copper
* SPC : Silver Plated Copper
* FEP : Fluorinated Ethylene Propylene

ELECRICAL DATA
ITEM SPECIFICATION
Temperature rating 150
Inner conductor resistance Max. 759 / km (20)
Insulation resistance Min. 1500 /km (20)
Voltaqe rating 250Vrms
Capacitance Nom. 98 pF/ft (1KHz)
Characteristic impedance 50 ± 5
Approx. weight 8.4 kg/km
Dielectric strength Dielectric core:
AC 1.5KV for 0.15sec
Spark test
Jacket:
AC 1.5KV for 0.15sec
Spark test
No breakdown at
AC 500V for 1min
Outer conductor
To inner conductor

Maximum Attenuation 1.0 GHz 2.5 dB/m
2.0 MHz 3.3 dB/m
3.0 GHz 3.9 dB/m
